Transparent Conductive Layers for Smart Glazing and Photovoltaic

Listing Description

This technology enables the development and deposition of transparent conductive oxide (TCO) thin films on both flat and flexible substrates for applications such as smart glazing, solar control, low-emissivity coatings, and photovoltaics. Utilizing advanced large-area sputtering and roll-to-roll processes, including DC, pulsed DC, RF-assisted, and reactive sputtering, the solution ensures scalable, high-quality coatings. Inline processing, in-situ monitoring, and post-treatment options such as annealing and flash lamp annealing enhance performance and reproducibility for optoelectronic applications.

Offer Details

Specifications and Deliverables:

• Substrate sizes up to 0.6 × 1.2 m² and roll-to-roll capability up to 600 mm width
• Film thickness ranging from 20 to 300 nm
• Optical transmittance greater than 85% in the visible spectrum
• Sheet resistance between 5 and 50 Ω/sq
• Deposition rates of 1–4 nm/s
• Materials including ITO, IZO, ZnO:Al (AZO), and ZnO
• In-situ monitoring and post-annealing up to 450°C (including flash lamp annealing)
• Deposition recipes, process data, and characterization (XRD, AFM, ellipsometry)
• Transmission spectra and sample coatings for evaluation

Value Proposition:

• High-performance transparent conductive coatings for smart glazing and photovoltaic applications
• Scalable large-area and roll-to-roll deposition for industrial production
• Robust interface quality with production-grade process control
• Wide material portfolio including ITO, IZO, and ZnO-based coatings
• Integrated process optimization with in-situ monitoring and post-treatment options

Input Required from Customer:

• Target optical transmittance and electrical conductivity (sheet resistance)
• Substrate type (glass, flexible substrate) and dimensions
• Application requirements (e.g., PV, smart glazing, display)
• Integration constraints and processing conditions
• Environmental and performance specifications

Fields of Application:
